The ST-320SElll injection molding machine is specifically designed for high-efficiency production of plastic items such as dustbins, chairs, and car bump pallets. Featuring a demoulding linkage that significantly shortens cycle times, the ST-320SElll offers high speed, stable performance, and energy-saving benefits. This allows for higher production output with the same labor and operational costs.
Professional Manufacturing: We specialize in plastic injection molding machines for a wide variety of plastic products. Our range includes clamping forces from 70 to 4000 Tons and injection weights from 50 to 10000g, all backed by CE and ISO certifications.
| Item | Unit | 320SElll (3200-1930) | ||
|---|---|---|---|---|
| Screw diameter | mm | 60 | 65 | 75 |
| Theoretical shot volume | cc | 919 | 1078 | 1436 |
| Shot weight (PS) | g | 836 | 981 | 1307 |
| Injection pressure | MPa | 210 | 179 | 134 |
| Injection rate | cm³/s | 306 | 359 | 477 |
| Clamping force | Ton | 320 | ||
| Max. daylight | mm | 1400 | ||
| Clamping stroke | mm | 700 | ||
| Distance btwn. tie bars | mm | 680*680 | ||
| Mould thickness range | mm | 250-700 | ||
| Motor power | kW | 40.9 | ||
| Net weight | Ton | 11.52 | ||
